Inwin P65F 650W 80+ Gold Power Supply
High-Performance Without Compromise
The PF Series is an 80 PLUS ® Gold certified power supply with up to 90% efficiency. It features a powerful single +12V rail design and multi-protection safeguards, which can provide reliability and great performance for high-end components. The PF Series offers high-performance without compromise, a great option for budget builds
Smart Thermal Control to Balance Cooling and Noise Pollution
The PF Series utilizes a smart temperature-controlled fan design. It automatically detects the heat to adjust the fan speed accordingly. It achieves the optimal balance between silent operation and excellent thermal performance.
5V and 3.3V DC to DC Design
Equipped with 5V and 3.3V DC to DC converter design, the PF Series provides a superior dynamic response, and supports a foundation for greater system stability.
SPECIFICATIONS:
| Model | P65F |
| Model Number | IW-PS-PF650W |
| Total Power | 650W |
| Materials | SECC |
| Type | ATX12V V2.52 |
| Cable Management | Non-Modular Cables |
| PFC | Active PFC (> 0.95) |
| Efficiency | 80 PLUS® Gold (Up to 90%) |
| MTBF (Hours) | > 100,000 hrs. |
| AC Input | 100-240Vac, 8-10A, 50-60Hz |
| Fan | 120mm Sleeve Bearing Fan |
| Typical Load Fan Noise(dBA) (50% Loading) |
< 25dBA |
| Operating Temperature Range (°C) | 0~40 °C |
| Full Protection | OCP / OVP / UVP / SCP / OTP / OPP |
| Safety Certifications | cTUVus / TUV / CB / CE / CCC / FCC / RCM / BSMI |
| Product Dimensions (L x W x H) |
140 x 150 x 86 mm |
| Package Dimensions (L x W x H) |
280 x 210 x 105 mm |
| Net Weight | 1.54 kg |
| Gross Weight | 2.0 kg |
High-Performance Without Compromise
The PF Series is an 80 PLUS ® Gold certified power supply with up to 90% efficiency. It features a powerful single +12V rail design and multi-protection safeguards, which can provide reliability and great performance for high-end components. The PF Series offers high-performance without compromise, a great option for budget builds
Smart Thermal Control to Balance Cooling and Noise Pollution
The PF Series utilizes a smart temperature-controlled fan design. It automatically detects the heat to adjust the fan speed accordingly. It achieves the optimal balance between silent operation and excellent thermal performance.
5V and 3.3V DC to DC Design
Equipped with 5V and 3.3V DC to DC converter design, the PF Series provides a superior dynamic response, and supports a foundation for greater system stability.
SPECIFICATIONS:
| Model | P65F |
| Model Number | IW-PS-PF650W |
| Total Power | 650W |
| Materials | SECC |
| Type | ATX12V V2.52 |
| Cable Management | Non-Modular Cables |
| PFC | Active PFC (> 0.95) |
| Efficiency | 80 PLUS® Gold (Up to 90%) |
| MTBF (Hours) | > 100,000 hrs. |
| AC Input | 100-240Vac, 8-10A, 50-60Hz |
| Fan | 120mm Sleeve Bearing Fan |
| Typical Load Fan Noise(dBA) (50% Loading) |
< 25dBA |
| Operating Temperature Range (°C) | 0~40 °C |
| Full Protection | OCP / OVP / UVP / SCP / OTP / OPP |
| Safety Certifications | cTUVus / TUV / CB / CE / CCC / FCC / RCM / BSMI |
| Product Dimensions (L x W x H) |
140 x 150 x 86 mm |
| Package Dimensions (L x W x H) |
280 x 210 x 105 mm |
| Net Weight | 1.54 kg |
| Gross Weight | 2.0 kg |
$19.27
Original: $64.24
-70%Inwin P65F 650W 80+ Gold Power Supply—
$64.24
$19.27Description
