Arctic P14 PWM PST A-RGB Semi-Passive



General Specifications

Performance

Fan Speed	200—1900 rpm PWM Controlled (0 rpm below 5% PWM)
Airflow	68.90 cfm | 117.06 m³/h
Static Pressure	2 mmH2O
Noise Level	0.3 Sone

Fan

Fan Frame	Standard
Control Type	PWM PST
Connector	4-Pin Connector + 4-Pin Socket
Fan Bearing	Fluid Dynamic Bearing
Operating Ambient Temperature	0—40 °C
Warranty	6 Years

Electric Characteristics

Typical Voltage	12 V DC
Starting Voltage	5 V
Current | Voltage	0.17 A | 12 V DC
Cable Length	400 mm

RGB Specifications

LEDs	12 A-RGB LEDs
Connector	3-Pin 5 V-DI-GND Connector
Current / Voltage	0.4 A/5 V
Cable	400 mm Cable with 80 mm Sharing Cable, Black

Size & Weight

Length	140 mm
Width	140 mm
Height	27 mm
Weight	225 g
